805 DOUBLE HINGED STAINLESS STEEL CHAIN
Free Shipping!!
| Pitch | 38,1mm |
| Thickness | 13mm |
| Open Surface Ratio (%) | Flat Top 0% |
| Width | As shown on the table |
| Colour | Metalic |
| Pin Diameter | 6,5mm |
| Major Diameter | Up to the sprocket dimensions |
| mm |  |
|||||||
|---|---|---|---|---|---|---|---|---|
| Stock Code | P | RI | PIN | Material | Kg / m | Meter (m) |
Feet (ft) |
|
| 805 OHI 190 | 190,5 | - | Stainless Steel (AISI 304) | Stainless Steel (HI) | 5,80 | 3,048 | 10 | |
| 805 HRC 190 | 190,5 | - | Stainless Steel (AISI 304) | Stainless Steel (43 HRC) | 5,80 | 3,048 | 10 | |
| 805 304 190 | 190,5 | - | Stainless Steel (AISI 304) | Stainless Steel (304 AISI) | 5,80 | 3,048 | 10 | |
| 805 430 190 | 190,5 | - | Stainless Steel (AISI 304) | Stainless Steel (430 AISI) | 5,80 | 3,048 | 10 | |
