821 BPM ROLLER STRAIGHT RUNNING PLATE CHAIN
Free Shipping!!
| Pitch | : 38,1mm |
| Thickness | : 31mm |
| Open Surface Ratio (%) | : Flat Top (%0) |
| Width | : As shown on the table |
| Colour | : Brown |
| Cleanability | : Average (FDA Food Grade) |
| Pin Diameter | : 6 mm |
| Major Diameter | : Up to the sprocket dimensions |
|
|
| mm |  |
|||||||
|---|---|---|---|---|---|---|---|---|
| Stock Code | RM | P | L | Material | PIN | Kg / m | Meter (m) | Feet (ft) |
| 821 BPM 190 | _ | 38,1 | 190,5 | POM Polyacetal | SS Stainless Stell (AISI 304) | 2,5 | 3,048 | 10 |
| 821 BPM 254 | _ | 38,1 | 254,0 | POM Polyacetal | SS Stainless Stell (AISI 304) | 2,95 | 3,048 | 10 |
| 821 BPM 304 | _ | 38,1 | 304 | POM Polyacetal | SS Stainless Stell (AISI 304) | 3,25 | 3,048 | 10 |
